Hydraulic 3 Roller Rolling Machine
We manufacture high-quality Hydraulic 3 Roller Rolling Machines to ensure precise and reliable bending of sheet metal and plates into cylindrical and conical shapes. With a strong focus on power, precision, and smooth operation, our machines deliver efficient rolling performance for a wide range of industrial applications. Robust engineering and customizable configurations meet the demands of modern fabrication, manufacturing, and structural workshops.
India’s Trusted Manufacturer of Rolling Machines
Industrial Hydraulic 3 Roller Rolling Machine for Modern Production
A Hydraulic 3 Roller Rolling Machine is a specialized bending machine that uses three hydraulic-driven rollers to form flat sheet metal into curved, cylindrical, or conical shapes. It is widely used for bending mild steel, stainless steel, aluminium, and other metals in workshops, fabrication units, and manufacturing industries. The hydraulic system ensures controlled and uniform force application, making it ideal for precise and repeatable rolling operations.
Speed
High-performance hydraulic system delivers strong and controllable force for smooth and efficient rolling operations.
Precision
Accurate roller alignment and hydraulic control ensure even bending and consistent radius formation across materials.
Durability
Heavy-duty construction with premium hydraulic and mechanical components ensures long service life and dependable performance.
Built with Proven Manufacturing Standards
3 Roll Hydraulic Rolling Design & Components
Find out about the design, build quality and features that make the Hydraulic 3 Roller Rolling Machine reliable for modern manufacturing processes.
HOUSINGS
The housings are fabricated from M.S. plates, following the Standard welding practice and machined accurately to house the bearings, which are the main journals for the rolls.
SHELL DISCHARGE END
The shell discharge will be done with hydraulically operated partially open.
BEARINGS
All the bearings for rolls are ‘ZKL’ or equivalent make and fitted in Precision Machined Steel Cast blocks.
GEARBOX
Machine will be provided with Special design PLANETORY GEARBOX this arrangement allows the machine to work at its maximum capacity without any overload and gives more efficiency & accuracy.
ELECTRIC MOTOR
All the electric motors of the machine will be CG/ABB/HAVELS
ADJUSTMENT
The Bottom / Side Rolls are adjusted hydraulically by means of Hydraulic Cylinders which are operated through movable control panel desk.
MOVABLE ELECTRIC CONTROL PANEL DESK
The machined is supplied with sophisticated electric control panel, having control of all the motors forwards as well as reverse direction. A control panel consists of following features:
• Two inching push buttons for Top Roll Motor
• M C B are provided to protect machine against short-circuit and over-loading.
• Emergency Stop Switch is fitted on control panel to avoid any Accident.
• Proper color coding for wires.
• Control desk can be operated with touch screen HMI and push buttons
• Control Panel would contain following functions:
i. Direction of feed/motor
ii. Braking of main drive
iii. Overload relays.
iv. Limit switches.
v. Electric interlocks.
vi. Independent fuses.
vii. Stop push button.
viii. Forward/reverse Push button.
ix. Up & Down Push Buttons.
x. Digital electronic type roll positioning indicator.
HYDRAULIC POWER PACK
• Complete hydraulic system with cylinders & power pack unit except hydraulic oil.
• Hydraulic oil tank with oil level indicator and filter (200 Ltrs)
• The main cylinder will be double acting type manufactured in carbon steel seamless pipe. The piston will be E.N.9 material with hard chrome plated & ground finished.
• The valves will be mounted on a well-designed and pressure tested manifold block. Alternately they may be threaded and sealed with suitable sill.
• Any conduit or hydraulic line in front of the press will be avoided.
• The oil level indicator on the power pack will be on the front side. The material that goes into the construction will be of good tested quality i.e. M.S prime material and of sufficient thickness.
ELECTRIC CONTROL PANEL
Variable Frequency Drive with push button panel
Review Specifications Before Making the Right Choice
Technical Specifications of Hydraulic 3 Roller Rolling Machine
| MODEL NO. | MAX. ROLLING WIDTH | ROLLING CAPACITY | PRE PINCHING CAPACITY (5T X TOP ROLL) | MINI. PLATE THICK. CAN ROLLING | TOP ROLL DIAMETER [APPROX.] | SIDE ROLL DIAMETER [APPROX.] | MAIN PUMP MOTOR H.P. | CAPACITY RATED FOR MS IN FULL SPAN | TYPE OF MACHINE | MIN. WIDTH OF FLAT END | MIN. SHELL I.D. IN FULL THICK. | GEAR BOX TYPE / MAKE | HYD. PUMP WORKING PRESSURE | LUB. SYSTEM | DROP END / SWING ARM | OVERALL DIMENSIONS (Length x Width x Heigth) | WEIGHT (APPROX.) |
| RP Roll 3H - 616 | 1600 | 4 | 4 | 40% OF RATED CAPACITY | 170 (+/- 5 mm) | 150 (+/- 5 mm) | 7.5+3 | MS PLATE OF 28 KG/MM2 YIELD STRENGTH | PYRAMID/DOUBLE PINCH | 5 X PLATE THICK. | 5 X TOP ROLL DIE. | PLANETARY/2.NOS/RAJESH | 180 | AUTO LUB.(BUSH TYPE) | HYD. OPERATED | 3020 x 1050 x 1080 | 2200 |
| RP Roll 3H - 621 | 2100 | 6 | 4 | 40% OF RATED CAPACITY | 160 | 180 | 2.2 | MS PLATE OF 28 KG/MM2 YIELD STRENGTH | PYRAMID/DOUBLE PINCH | 5 X PLATE THICK. | 5 X TOP ROLL DIE. | PLANETARY/2.NOS/RAJESH | 180 | AUTO LUB.(BUSH TYPE) | HYD. OPERATED | 4200 x 1350 x 1300 | 2700 |
| RP Roll 3H - 626 | 2600 | 6 | 4 | 40% OF RATED CAPACITY | 190 | 170 | 3 | MS PLATE OF 28 KG/MM2 YIELD STRENGTH | PYRAMID/DOUBLE PINCH | 5 X PLATE THICK. | 5 X TOP ROLL DIE. | PLANETARY/2.NOS/RAJESH | 180 | AUTO LUB.(BUSH TYPE) | HYD. OPERATED | 4650 x 1350 x 1300 | 4200 |
| RP Roll 3H - 631 | 3100 | 6 | 4 | 40% OF RATED CAPACITY | 210 | 190 | 7.5 | MS PLATE OF 28 KG/MM2 YIELD STRENGTH | PYRAMID/DOUBLE PINCH | 5 X PLATE THICK. | 5 X TOP ROLL DIE. | PLANETARY/2.NOS/RAJESH | 180 | AUTO LUB.(BUSH TYPE) | HYD. OPERATED | 5150 x 1350 x 1300 | 5600 |
| RP Roll 3H - 641 | 4100 | 6 | 4 | 40% OF RATED CAPACITY | 270 | 250 | 7.5 | MS PLATE OF 28 KG/MM2 YIELD STRENGTH | PYRAMID/DOUBLE PINCH | 5 X PLATE THICK. | 5 X TOP ROLL DIE. | PLANETARY/2.NOS/RAJESH | 180 | AUTO LUB.(BUSH TYPE) | HYD. OPERATED | 6400 x 1600 x 1650 | 10500 |
| RP Roll 3H - 821 | 2100 | 8 | 6 | 40% OF RATED CAPACITY | 190 | 180 | 3 | MS PLATE OF 28 KG/MM2 YIELD STRENGTH | PYRAMID/DOUBLE PINCH | 5 X PLATE THICK. | 5 X TOP ROLL DIE. | PLANETARY/2.NOS/RAJESH | 180 | AUTO LUB.(BUSH TYPE) | HYD. OPERATED | 4200 x 1350 x 1300 | 3800 |
| RP Roll 3H - 826 | 2600 | 8 | 6 | 40% OF RATED CAPACITY | 210 | 190 | 7.5 | MS PLATE OF 28 KG/MM2 YIELD STRENGTH | PYRAMID/DOUBLE PINCH | 5 X PLATE THICK. | 5 X TOP ROLL DIE. | PLANETARY/2.NOS/RAJESH | 180 | AUTO LUB.(BUSH TYPE) | HYD. OPERATED | 4560 x 1350 x 1300 | 5400 |
| RP Roll 3H - 831 | 3100 | 8 | 6 | 40% OF RATED CAPACITY | 230 | 210 | 7.5 | MS PLATE OF 28 KG/MM2 YIELD STRENGTH | PYRAMID/DOUBLE PINCH | 5 X PLATE THICK. | 5 X TOP ROLL DIE. | PLANETARY/2.NOS/RAJESH | 180 | AUTO LUB.(BUSH TYPE) | HYD. OPERATED | 5250 x 1500 x 1600 | 6600 |
| RP Roll 3H - 841 | 4100 | 8 | 6 | 40% OF RATED CAPACITY | 300 | 270 | 7.5 | MS PLATE OF 28 KG/MM2 YIELD STRENGTH | PYRAMID/DOUBLE PINCH | 5 X PLATE THICK. | 5 X TOP ROLL DIE. | PLANETARY/2.NOS/RAJESH | 180 | AUTO LUB.(BUSH TYPE) | HYD. OPERATED | 6650 x 1850 x 1800 | 11700 |
| RP Roll 3H - 1021 | 2100 | 10 | 8 | 40% OF RATED CAPACITY | 210 | 190 | 7.5 | MS PLATE OF 28 KG/MM2 YIELD STRENGTH | PYRAMID/DOUBLE PINCH | 5 X PLATE THICK. | 5 X TOP ROLL DIE. | PLANETARY/2.NOS/RAJESH | 180 | AUTO LUB.(BUSH TYPE) | HYD. OPERATED | 4150 x 1350 x 1300 | 5100 |
| RP Roll 3H - 1026 | 2600 | 10 | 8 | 40% OF RATED CAPACITY | 230 | 210 | 7.5 | MS PLATE OF 28 KG/MM2 YIELD STRENGTH | PYRAMID/DOUBLE PINCH | 5 X PLATE THICK. | 5 X TOP ROLL DIE. | PLANETARY/2.NOS/RAJESH | 180 | AUTO LUB.(BUSH TYPE) | HYD. OPERATED | 4750 x 1500 x 1600 | 6500 |
| RP Roll 3H - 1031 | 3100 | 10 | 8 | 40% OF RATED CAPACITY | 270 | 250 | 11 | MS PLATE OF 28 KG/MM2 YIELD STRENGTH | PYRAMID/DOUBLE PINCH | 5 X PLATE THICK. | 5 X TOP ROLL DIE. | PLANETARY/2.NOS/RAJESH | 180 | AUTO LUB.(BUSH TYPE) | HYD. OPERATED | 5400 x 1600 x 1650 | 9100 |
| RP Roll 3H - 1041 | 4100 | 10 | 8 | 40% OF RATED CAPACITY | 330 | 300 | 7.5 | MS PLATE OF 28 KG/MM2 YIELD STRENGTH | PYRAMID/DOUBLE PINCH | 5 X PLATE THICK. | 5 X TOP ROLL DIE. | PLANETARY/2.NOS/RAJESH | 180 | AUTO LUB.(BUSH TYPE) | HYD. OPERATED | 6450 x 2050 x 2000 | 17500 |
| RP Roll 3H - 1321 | 2100 | 13 | 10 | 40% OF RATED CAPACITY | 230 | 210 | 7.5 | MS PLATE OF 28 KG/MM2 YIELD STRENGTH | PYRAMID/DOUBLE PINCH | 5 X PLATE THICK. | 5 X TOP ROLL DIE. | PLANETARY/2.NOS/RAJESH | 180 | AUTO LUB.(BUSH TYPE) | HYD. OPERATED | 4250 x 1500 x 1600 | 5700 |
| RP Roll 3H - 1326 | 2600 | 13 | 10 | 40% OF RATED CAPACITY | 270 | 250 | 11 | MS PLATE OF 28 KG/MM2 YIELD STRENGTH | PYRAMID/DOUBLE PINCH | 5 X PLATE THICK. | 5 X TOP ROLL DIE. | PLANETARY/2.NOS/RAJESH | 180 | AUTO LUB.(BUSH TYPE) | HYD. OPERATED | 4900 x 1600 x 1650 | 7400 |
| RP Roll 3H - 1331 | 3100 | 13 | 10 | 40% OF RATED CAPACITY | 300 | 270 | 11 | MS PLATE OF 28 KG/MM2 YIELD STRENGTH | PYRAMID/DOUBLE PINCH | 5 X PLATE THICK. | 5 X TOP ROLL DIE. | PLANETARY/2.NOS/RAJESH | 180 | AUTO LUB.(BUSH TYPE) | HYD. OPERATED | 5650 x 1900 x 1850 | 11000 |
| RP Roll 3H - 1341 | 4100 | 13 | 10 | 40% OF RATED CAPACITY | 360 | 330 | 11 | MS PLATE OF 28 KG/MM2 YIELD STRENGTH | PYRAMID/DOUBLE PINCH | 5 X PLATE THICK. | 5 X TOP ROLL DIE. | PLANETARY/2.NOS/RAJESH | 180 | AUTO LUB.(BUSH TYPE) | HYD. OPERATED | 6600 x 2050 x 2100 | 18800 |
| RP Roll 3H - 1621 | 2100 | 16 | 13 | 40% OF RATED CAPACITY | 270 | 250 | 11 | MS PLATE OF 28 KG/MM2 YIELD STRENGTH | PYRAMID/DOUBLE PINCH | 5 X PLATE THICK. | 5 X TOP ROLL DIE. | PLANETARY/2.NOS/RAJESH | 180 | AUTO LUB.(BUSH TYPE) | HYD. OPERATED | 4400 x 1600 x 1650 | 6800 |
| RP Roll 3H - 1626 | 2600 | 16 | 13 | 40% OF RATED CAPACITY | 300 | 270 | 11 | MS PLATE OF 28 KG/MM2 YIELD STRENGTH | PYRAMID/DOUBLE PINCH | 5 X PLATE THICK. | 5 X TOP ROLL DIE. | PLANETARY/2.NOS/RAJESH | 180 | AUTO LUB.(BUSH TYPE) | HYD. OPERATED | 5150 x 1850 x 1850 | 9900 |
| RP Roll 3H - 1631 | 3100 | 16 | 13 | 40% OF RATED CAPACITY | 330 | 300 | 15 | MS PLATE OF 28 KG/MM2 YIELD STRENGTH | PYRAMID/DOUBLE PINCH | 5 X PLATE THICK. | 5 X TOP ROLL DIE. | PLANETARY/2.NOS/RAJESH | 180 | AUTO LUB.(BUSH TYPE) | HYD. OPERATED | 5450 x 2050 x 2000 | 14000 |
| RP Roll 3H - 1641 | 4100 | 16 | 13 | 40% OF RATED CAPACITY | 390 | 360 | 15 | MS PLATE OF 28 KG/MM2 YIELD STRENGTH | PYRAMID/DOUBLE PINCH | 5 X PLATE THICK. | 5 X TOP ROLL DIE. | PLANETARY/2.NOS/RAJESH | 180 | AUTO LUB.(BUSH TYPE) | HYD. OPERATED | 7050 x 2200 x 2300 | 24300 |
| RP Roll 3H - 2021 | 2100 | 20 | 16 | 40% OF RATED CAPACITY | 300 | 270 | 15 | MS PLATE OF 28 KG/MM2 YIELD STRENGTH | PYRAMID/DOUBLE PINCH | 5 X PLATE THICK. | 5 X TOP ROLL DIE. | PLANETARY/2.NOS/RAJESH | 180 | AUTO LUB.(BUSH TYPE) | HYD. OPERATED | 4650 x 1850 x 1850 | 8900 |
| RP Roll 3H - 2026 | 2600 | 20 | 16 | 40% OF RATED CAPACITY | 330 | 300 | 15 | MS PLATE OF 28 KG/MM2 YIELD STRENGTH | PYRAMID/DOUBLE PINCH | 5 X PLATE THICK. | 5 X TOP ROLL DIE. | PLANETARY/2.NOS/RAJESH | 180 | AUTO LUB.(BUSH TYPE) | HYD. OPERATED | 4950 x 2050 x 2000 | 12300 |
| RP Roll 3H - 2031 | 3100 | 20 | 16 | 40% OF RATED CAPACITY | 360 | 330 | 15 | MS PLATE OF 28 KG/MM2 YIELD STRENGTH | PYRAMID/DOUBLE PINCH | 5 X PLATE THICK. | 5 X TOP ROLL DIE. | PLANETARY/2.NOS/RAJESH | 180 | AUTO LUB.(BUSH TYPE) | HYD. OPERATED | 5600 x 2050 x 2100 | 17100 |
| RP Roll 3H - 2041 | 4100 | 20 | 16 | 40% OF RATED CAPACITY | 430 | 390 | 18.5 | MS PLATE OF 28 KG/MM2 YIELD STRENGTH | PYRAMID/DOUBLE PINCH | 5 X PLATE THICK. | 5 X TOP ROLL DIE. | PLANETARY/2.NOS/RAJESH | 180 | AUTO LUB.(BUSH TYPE) | HYD. OPERATED | 7200 x 2350 x 2350 | 29900 |
| RP Roll 3H - 2521 | 2100 | 25 | 20 | 40% OF RATED CAPACITY | 330 | 300 | 15 | MS PLATE OF 28 KG/MM2 YIELD STRENGTH | PYRAMID/DOUBLE PINCH | 5 X PLATE THICK. | 5 X TOP ROLL DIE. | PLANETARY/2.NOS/RAJESH | 180 | AUTO LUB.(BUSH TYPE) | HYD. OPERATED | 4450 x 2050 x 2000 | 11100 |
| RP Roll 3H - 2526 | 2600 | 25 | 20 | 40% OF RATED CAPACITY | 360 | 330 | 18.5 | MS PLATE OF 28 KG/MM2 YIELD STRENGTH | PYRAMID/DOUBLE PINCH | 5 X PLATE THICK. | 5 X TOP ROLL DIE. | PLANETARY/2.NOS/RAJESH | 180 | AUTO LUB.(BUSH TYPE) | HYD. OPERATED | 5100 x 2050 x 2100 | 15500 |
| RP Roll 3H - 2531 | 3100 | 25 | 20 | 40% OF RATED CAPACITY | 390 | 360 | 18.5 | MS PLATE OF 28 KG/MM2 YIELD STRENGTH | PYRAMID/DOUBLE PINCH | 5 X PLATE THICK. | 5 X TOP ROLL DIE. | PLANETARY/2.NOS/RAJESH | 180 | AUTO LUB.(BUSH TYPE) | HYD. OPERATED | 6050 x 2200 x 2350 | 21100 |
| RP Roll 3H - 2541 | 4100 | 25 | 20 | 40% OF RATED CAPACITY | 460 | 420 | 22 | MS PLATE OF 28 KG/MM2 YIELD STRENGTH | PYRAMID/DOUBLE PINCH | 5 X PLATE THICK. | 5 X TOP ROLL DIE. | PLANETARY/2.NOS/RAJESH | 180 | AUTO LUB.(BUSH TYPE) | HYD. OPERATED | 7400 x 2650 x 2400 | 40300 |
| RP Roll 3H - 3021 | 2100 | 30 | 25 | 40% OF RATED CAPACITY | 360 | 330 | 19 | MS PLATE OF 28 KG/MM2 YIELD STRENGTH | PYRAMID/DOUBLE PINCH | 5 X PLATE THICK. | 5 X TOP ROLL DIE. | PLANETARY/2.NOS/RAJESH | 180 | AUTO LUB.(BUSH TYPE) | HYD. OPERATED | 4700 x 2100 x 2100 | 12200 |
| RP Roll 3H - 3026 | 2600 | 30 | 25 | 40% OF RATED CAPACITY | 390 | 360 | 22 | MS PLATE OF 28 KG/MM2 YIELD STRENGTH | PYRAMID/DOUBLE PINCH | 5 X PLATE THICK. | 5 X TOP ROLL DIE. | PLANETARY/2.NOS/RAJESH | 180 | AUTO LUB.(BUSH TYPE) | HYD. OPERATED | 5500 x 2200 x 2250 | 18500 |
| RP Roll 3H - 3031 | 3100 | 30 | 28 | 40% OF RATED CAPACITY | 430 | 390 | 22 | MS PLATE OF 28 KG/MM2 YIELD STRENGTH | PYRAMID/DOUBLE PINCH | 5 X PLATE THICK. | 5 X TOP ROLL DIE. | PLANETARY/2.NOS/RAJESH | 180 | AUTO LUB.(BUSH TYPE) | HYD. OPERATED | 6200 x 2350 x 2350 | 26400 |
| RP Roll 3H - 3041 | 4100 | 30 | 25 | 40% OF RATED CAPACITY | 510 | 460 | 30 | MS PLATE OF 28 KG/MM2 YIELD STRENGTH | PYRAMID/DOUBLE PINCH | 5 X PLATE THICK. | 5 X TOP ROLL DIE. | PLANETARY/2.NOS/RAJESH | 180 | AUTO LUB.(BUSH TYPE) | HYD. OPERATED | 7500 x 3000 x 2700 | 42900 |
Engineered for Precision. Designed for Continuous Production.
Key Advantages of Hydraulic 3 Roller Rolling Machine
Our Hydraulic 3 Roller Rolling Machines combine heavy-duty engineering with precision design to deliver reliable, high-performance rolling in demanding production environments.
Powerful and Controlled Rolling Force
Hydraulic drive provides smooth and uniform force, enabling precise bending of sheet metal into curved profiles. Delivers reliable performance for both light and heavy rolling applications.
High Productivity
Efficient hydraulic operation and smooth rolling action increase output and reduce setup time. Ideal for continuous production environments.
Consistent and Accurate Bending
Precision-engineered rollers and hydraulic control ensure even bending and consistent radius formation. Reduces the need for secondary adjustments and improves overall quality.
Versatile Material Handling
Suitable for mild steel, stainless steel, aluminium, and other sheet metals with dependable performance. Maintains consistent rolling quality across different materials and thicknesses.
Adjustable Roller Configuration
Allows easy adjustment of roller positions to accommodate different material thicknesses and shapes. Enhances versatility for varied fabrication requirements.
User‑Friendly Operation
Simple control interface makes machine operation intuitive and efficient. Reduces operator fatigue and improves workshop workflow.
Standard Features & Optional Upgrades
Configured to Match Your Production Requirements
Rajesh Hydraulic 3 Roller Rolling Machines are developed precisely to meet the rigorous requirements of modern metal fabrication and structural manufacturing processes. Built with a robust frame, advanced hydraulic system, and precision-engineered rollers, these machines provide excellent stability, precise force distribution, and smooth operation.
Each machine is thoughtfully designed to ensure steady performance, enhanced safety features, and long-lasting endurance — making it an ideal solution for workshops and manufacturing units focused on productivity, reliability, and quality output.
Standard Equipment
- Double Pre Pinch Hydraulically
- 7” Delta Colour Touch Screen HMI
- 2 Planetary Gear Box Powered by individual Hydro Motor
- 4 Nos. High Precision Linear Scale
- PLC Control Panel with Programming Facility
- Centralized Auto Lubrication System
- Siemens Electric Motor
- Schneider (France) PLC
- Siemens/Schneider/Sulzer Electric Panel Components
Optional Equipment
- Conical Bending Device
- Oil Cooler Heat Exchanger with Water Coolant System
- Oil Cooler Heat Exchanger with Air Coolant System with pump, Radiator & fan
Find the Best 3 Roll Rolling Machine Within Your Budget
3 Roll Rolling Machine Price
| 3 ROLL ROLLING MACHINE | ||
| DESCRIPTION | MAX. ROLLING WIDTH | Website Price - Starting From |
| RP Roll 3H - 616 | 1600 | 1,350,000 |
| RP Roll 3H - 621 | 2100 | 1,450,000 |
| RP Roll 3H - 626 | 2600 | 1,800,000 |
| RP Roll 3H - 1621 | 2100 | 2,200,000 |
| RP Roll 3H - 1626 | 2600 | 2,650,000 |
| RP Roll 3H - 2021 | 2100 | 2,600,000 |
| RP Roll 3H - 2026 | 2600 | 3,150,000 |
| RP Roll 3H - 2531 | 3100 | 4,500,000 |
| RP Roll 3H - 3026 | 2600 | 4,400,000 |
| RP Roll 3H - 3031 | 3100 | 5,250,000 |
| RP Roll 3H - 2541 | 2600 | 5,500,000 |
| RP Roll 3H - 3050 | 3000 | 10,100,000 |
From Light-Duty to Heavy-Duty Applications
C-Frame Power Press Machines by Tonnage Capacity
rcp10
Learn More →
rcp10
Learn More →
rcp10
Learn More →
rcp10
Learn More →
rcp10
Learn More →
rcp10
Learn More →
Quality Assurance Through
Our Certificates
Why Choose Rajesh Hydraulic 3 Roller Rolling Machines
Hydraulic 3 Roller Rolling Machines are designed to deliver smooth, accurate plate rolling for a wide range of fabrication applications. Their heavy-duty structure, synchronized roll movement, and precision controls ensure uniform bending performance, making them ideal for production units that demand both accuracy and efficiency.
Each machine is manufactured using premium-quality materials and advanced engineering techniques to provide long-lasting durability, stable operation, and reduced vibration. The solid frame construction supports continuous workloads while maintaining consistent rolling quality and minimizing maintenance interruptions.
Rajesh Power Press India manufactures these machines with flexible configuration options including variable capacities, hydraulic adjustments, and automation integrations to suit diverse industrial requirements. Supported by dependable service assistance and authentic spare components, these machines help businesses achieve reliable productivity and long-term operational value.
Let’s Build Your Production Power
Get in Touch with Our Experts
People Also Ask
Frequently Asked Questions
The Hydraulic 3‑Roller Rolling Machine is designed to curve, bend, and roll metal plates into cylindrical and arc‑shaped sections. Its three‑roller configuration allows the plate to be progressively rolled to the required radius, making it suitable for medium to heavy plate rolling applications.
Standard features include double pre‑pinch hydraulic control, PLC control panel with programming facility, colour touch‑screen HMI, hydraulic adjustment for rolls, centralized auto lubrication system, and a movable control desk with emergency stop and forward/reverse controls for safe and precise operation.
Yes. Optional features can be added based on production needs, such as conical bending devices and oil cooler heat exchangers (with water or air cooling) to improve performance, cooling efficiency, and flexibility for specific material handling requirements.
